VXDIAG VCX FD for GM for Ford/Mazda 2 in 1 Car Diagnostic Tool Support DoIP and CAN FD ECU Coding

The VXDIAG VCX-FD is a cutting-edge, dual-core processor-powered diagnostic interface designed for Ford and Mazda vehicles. It supports advanced protocols like CAN FD and DoIP, making it a versatile tool for both traditional and modern vehicles. Whether you're a professional technician or a car enthusiast, this guide will walk you through its features, installation, and usage.

Why Choose the VXDIAG VCX-FD?

Top Features of the VXDIAG VCX-FD

The VXDIAG VCX-FD stands out as a next-generation diagnostic tool with a range of features that make it indispensable for Ford and Mazda diagnostics:

1. Ford IDS V130 & Mazda IDS V131 Compatibility

   • Perfect for diagnosing and reprogramming Ford and Mazda vehicles with the latest software versions.

2. Multi-Language Support

   • Supports English, German, French, Italian, Dutch, Spanish, Swedish, Finnish, Danish, Norwegian, Portuguese (European), and Portuguese (Brazil).

3. CAN FD and DoIP Protocol Support

   • Works seamlessly with modern vehicles using the latest communication protocols.

4. Vehicle Coverage

   • Covers Ford and Mazda vehicles from 2005 to 2024, including the Ford F-Series after 2010.

5. Replacement for Ford VCM2

   • A cost-effective and powerful alternative to the Ford VCM2.

6. Software Compatibility

   • Compatible with IDS, ForScan, FJDS, FDRS, and MDARS. For newer models (post-2020), FDRS or MDARS are required.

Technical Specifications of the VXDIAG VCX-FD

Supported Protocols

• ISO-15765 CAN / CANFD
• ISO-13400 DoIP Option1/2
• ISO-9141 K-Line
• ISO-14230 K-Line
• ISO-17987 LIN BUS
• SAE-J1850-PWM (FORD SCP)
• ISO-11898-2 DWCAN
• ISO-11898-3 DWFTCAN
• FORD UBP

LED Indicators

• Power LED (Red): Indicates device status (breathing flash for normal startup, rapid flash for hardware failure).
• Vehicle LED (Two-Color): Blue for traditional protocols, green for DoIP communication.
• WiFi LED (Blue): Quick flashes during wireless communication, slow flashes during distribution.
• Connection LED (Two-Color): Blue for USB communication, green for LAN.
• Fn Button (Green): Slow flash after remote connection, quick flash during remote diagnosis.

Installation Requirements and Instructions

System Requirements

• Operating System: Windows 10/11 Pro (64-bit)
• RAM: 8GB or more
• Note: Ensure no other diagnostic software is installed. Ford IDS and Mazda IDS must be installed on separate, clean Windows systems.

Ford IDS Installation Steps

1. Install Ford IDS-1.
2. Wait for the installation to complete and restart your computer.
3. Install the Ford original VCI software (version 1.0.0.10).
4. Launch VX Manager and install the IDS driver from the "Diagnostic" menu.
5. Connect the VCX device and install idspatch.
6. Use idspatch to open IDS and start diagnosis.

Mazda IDS Installation Steps

1. Install Mazda IDS-1.
2. Wait for the installation to complete and restart your computer.
3. Launch VX Manager and install the IDS driver from the "Diagnostic" menu.
4. Connect the VCX device and install idspatch.
5. Use idspatch to open Mazda IDS and start diagnosis.

Key Functions of the VXDIAG VCX-FD

The VXDIAG VCX-FD is equipped with a wide range of diagnostic and programming functions, including:

1. Programming & Installation of ECUs

   • PCM, ABS, Instrument Cluster, Airbag, Fuel Pumps, etc.

2. Live Data-stream with Recording & Playback

3. Read & Clear DTCs (Diagnostic Trouble Codes)

4. Adjust or Remove Speed Governors

5. Automatic Vehicle Recognition

6. ECU Software Re-flash

7. Steering Angle Resets

8. Guided Fault Finding

9. Key Programming

10. DPF Regeneration

11. Brake Bleeding

12. Injector Coding

How to Set Up and Use the VXDIAG VCX-FD

Software Installation

1. Download and install the required software (installation links not provided).
2. Install the latest VX Manager from www.alicar.com.
3. Launch VX Manager, ensuring your network connection is stable.
4. Connect the device via USB cable/WiFi to your computer and the OBD2 port of your vehicle.
5. Install the PassThru driver and check your device license.
6. Turn on the car ignition and start diagnosing.

Connection and LED Status

• Power LED: Red (breathing flash during normal startup, rapid flash during hardware failure).
• Vehicle LED: Blue (traditional protocol), Green (DoIP protocol).
• WiFi LED: Blue (quick flash during wireless communication, slow flash during distribution).
• Connection LED: Blue (USB communication), Green (LAN communication).

Tips for a Smooth Installation

• Disable Antivirus Software: Ensure no interference during installation.
• Clean Windows Systems: Install Ford IDS and Mazda IDS on separate systems.
• Network Stability: A stable internet connection is essential for software updates and remote diagnostics.

Conclusion

The VXDIAG VCX-FD is an advanced car diagnostic tool designed for professionals and enthusiasts alike. With its support for CAN FD, DoIP, and compatibility with Ford IDS V130 and Mazda IDS V131, it offers a comprehensive solution for modern and legacy vehicles. Follow the installation and usage guide above to maximize its potential and streamline your diagnostic workflow.
