High Quality Single Board Autocom DS150e Diagnostic Tool New VCI Support Car Truck Bluetooth with keygen auto Device

The Autocom DS150E diagnostic tool is a game-changer for automotive professionals, offering extensive features tailored for both cars and trucks. With its brand-specific diagnostics and advanced capabilities, the DS150E allows technicians to perform a comprehensive range of tests across various vehicle models. If you're looking to enhance your diagnostic capabilities, the Autocom DS150E is an excellent investment.

Key Features of the DS150E Diagnostic Tool

Manufacturer-Specific Diagnostics

The DS150E excels in manufacturer-specific serial diagnostics, supporting vehicles from various brands. With the CARS software, you can perform diagnostics on cars and light vans from 1988 onwards, covering a total of 47 different brands. The TRUCKS software allows diagnostics for light and heavy commercial vehicles, buses, and trailers from 1995 onwards, encompassing 37 brands.

Comprehensive Diagnostic Functions

The DS150E offers a multitude of diagnostic functions, including:

• Engine
• Ignition
• Climate Control
• Anti-lock Braking System (ABS)
• Service Reset
• Supplemental Restraint System (SRS)
• Immobilizer
• Instrument Cluster
• Comfort Systems
• Gearbox

EOBD/OBDII Communication

Equipped with EOBD/OBDII communication capability, the DS150E meets legislation-based diagnostic requirements, specifically targeting emission-related fault codes. This ensures compliance and improves the efficiency of diagnostics.

Advanced Multiplexer Technology

The ds150e scan tool utilizes advanced multiplexer technology that supports a wide array of communication protocols, including:

• 2xHS CAN (ISO 11898-2)
• SW CAN (SAE J2411)
• K/L (ISO 9141-2)
• VPW (J1850)
• PWM (J1850)
• RS485 (J1708)
• TTL
• SPI

This versatility makes the DS150E suitable for various types of vehicles, regardless of voltage levels and communication standards.

Multi-Functional Capabilities

Flight Recorder Function

The flight recorder function allows real-time parameter recording while driving. This feature enables you to pinpoint specific errors, facilitating easier analysis later on. Moreover, the integrated memory eliminates the need to bring an external computer, although a memory card is not included in the package.

Multi-Colors Indicator

The multi-colors indicator provides essential feedback on the diagnostic process. Different colors and sounds communicate the status clearly, ensuring visibility from a distance. For example, alternating blue and green signals indicate active communication with the vehicle control unit.

LED Connector for Easy Access

A 16-pin connector equipped with an LED light makes it easy to locate the diagnostic connector, even in dark or hard-to-reach areas. This feature is particularly useful when using adapter cables for vehicles that do not have a standard diagnostic socket.

Voltage Check Feature

When connected to a vehicle, the DS150E automatically checks the battery voltage and adjusts accordingly (12 or 24 volts). It provides audio-visual alerts if voltage levels exceed safe limits, ensuring that diagnostics can proceed without interruption.

Chassis Number VIN Recognition

The CARS software incorporates a chassis number recognition feature. It reads the chassis number from the vehicle, ensuring automatic selection of the correct model and year. This function enhances overall diagnostic accuracy.

Intelligent System Scan (ISS)

The Intelligent System Scan (ISS) function scans all systems within the vehicle and presents stored fault codes efficiently. This comprehensive overview allows technicians to identify issues quickly and focus on specific control systems for deeper analysis.

Intelligent System Identification (ISI)

The Intelligent System Identification (ISI) feature automatically recognizes the type of controller in the vehicle, ensuring that the diagnostic session is executed accurately with all necessary parameters.

Report Function

The report function allows you to view possible adaptations and adjustments for specific vehicles without needing them present. Coupled with guiding texts, this capability aids in planning and conducting effective diagnostics even in complex scenarios.

Language and Compatibility Support

The Autocom DS150E supports various languages, including:

• Bulgarian, Croatian, Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek, Hungarian, Italian, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Romanian, Russian, Serbian, Spanish, Swedish, Turkish.

System Compatibility

This diagnostic tool is compatible with:

• Windows 7
• Windows 8 (32-bit and 64-bit)
• Windows 10 (32-bit and 64-bit)
• Tablets (dependent on computer configuration)

Conclusion

The Autocom DS150E is an indispensable diagnostic tool for automotive professionals, offering a robust suite of features for comprehensive vehicle diagnostics. With its extensive compatibility and advanced functionality, it simplifies fault detection and helps streamline repair processes.
